EN-18 7000 Series Indicators
CAL
3 PT LINEAR
CAL
5 PT LINEAR
3LIN
kg
10
3LIN
lb
5
3LIN
kg
5
3LIN
lb
--C--
3LIN
lb
2.5
0.000
lb
3LIN
lb
DONE
3LIN
lb
--C--
3LIN
lb
0
5LIN
kg
15
5LIN
lb
10
5LIN
kg
10
5LIN
lb
--C--
5LIN
lb
7.5
3LIN
lb
--C--
3.3.3 3 Point Linearity Calibration
Use this calibration method to adjust the zero calibration point, 1/2 and full load calibration points.
With no load on the scale, press the
Yes button. The display shows the current full load calibration
point and calibration unit of measure.
NOTES: To change the full load calibration point, press the No button and enter the value using the
keypad. Then press the
Yes button.
To change the calibration unit of measure, press the
No button to alternate between kg and
lb.
Place the specified full load calibration weight on the scale and press the
Yes button. The display
shows --C--, followed by the 1/2 load calibration point.
Place the specified 1/2 load calibration weight on the scale and press the
Yes button. The display
shows --C--, followed by the zero calibration point.
With no load on the scale, press the
Yes button. The display shows --C--, then DONE and returns to
the current application mode.
3.3.4 5 Point Linearity Calibration
Use this calibration method to adjust the zero calibration point, 1/4, 1/2, 3/4 and full load
calibration points
With no load on the scale, press the
Yes button. The display shows the current full load calibration
point and calibration unit of measure.
NOTES: To change the full load calibration point, press the No button and enter the value using the
keypad. Then press the
Yes button.
To change the calibration unit of measure, press the
No button to alternate between kg and
lb.
Place the specified full load calibration weight on the scale and press the
Yes button. The display
shows --C--, followed by the 3/4 load calibration point.
