TECHNICAL INFORMATION
113
TECHNICAL INFORMATION
SPECIFICATIONS
SOUND CONTROL SEQUENCER
6 internal sequencer tracks.
6 external MIDI sequencer tracks
128 x 64 step patterns
24 songs
3072 songs (+Drive models only)
Supports swing, slide and accent
62 possible parameter locks on each pattern step
12 multi functional programmable Arpeggiators
18 tempo synced interlaced LFO´s
Full MIDI support
SOUND GENERATION SYSTEM
5 Mono Synths
14 individual audio generating machines
4 individual stereo effect machines
5 effects on each track
6 part synthesis
128 kits
16384 kits (+Drive models only)
Monomachine SFX-60 MKII only
64 user waveform slots
8192 user waveform slots (+Drive models only)
TRACK EFFECTS
Tape-style Tempo-synced Delay
1-Band EQ
Resonant 24dB lp/bp/hp filter
Sample rate reduction
Distortion
MONO SYNTHS
SuperWave analogue style synthesis
SID MOS 6581 computer style synthesis
DigiPRO digital wavetable and beatbox
FM+ frequency modulation synthesis
V0-6 vocal synthesizer
FX SYNTH
Reverb, gated stereo plate reverb
Chorus, stereo 6 tap chorus
Dynamix, dynamics compressor
Ring Modulator
Phaser
Flanger
ELECTRICAL SPECIFICATIONS
Impedance balanced audio outputs:
Main out level: +15dBu
Assignable outs level: +10dBu
Output impedance: 100 unbalanced
S/N ratio: 100dBFS (20-20.000Hz)
Unbalanced audio inputs:
Input level: +7dBu maximum
Audio input impedance: 9 k
SNR inputs: 98dBFS (20-20.000Hz)
Unit power consumption: 10W typical, 18W maximum.
Recommended power supply: 6V DC, 3A
HARDWARE
128x64 pixel backlit LCD
MIDI In/Out/Thru
6 x 1/4” impedance balanced audio out jacks
2 x 1/4” audio in jacks
1 x 1/4” stereo headphone jack
Advanced dual DSP system
44.1kHz, 24-bit D/A and A/D converters
Flash-EEPROM upgradable OS
+Drive (+Drive equipped models only)
PHYSICAL SPECIFICATIONS
Steel casing with brushed aluminium panel
Dimensions: W340xD176xH63mm
(height including knobs and rubber feet)
Weight: approximately 2.8 kg
POWER SUPPLY (PSU-2) ELECTRICAL SPECIFICATIONS
Input voltage range: 100-240V (43-60Hz)
Input connector: IEC320-C8 (2 prong)
In-rush current: 50A maximum
Output voltage: 5.7-6.3V DC
Output current: 3.5A maximum
Output connector: 5.5x2.5mm DC plug, power at center
Ω
Ω
