TECHNICAL INFORMATION
75
TECHNICAL INFORMATION
SPECIFICATIONS
THE SEQUENCER
4 synth tracks
1 FX track
1 CV/Gate track
128 projects (+Drive)
4096 sounds (+Drive Sound library)
128 patterns (per project)
Up to 64 steps per pattern
128 Sounds (per project)
128 Kits (per project)
16 Songs (per project)
6× arpeggiators
Individual track lengths
Swing, slide and accent functions
Track transpose
Micro timing
Parameter locks
Live friendly Performance mode
Sound-per-step change
Instant kit, pattern, track and Sound reload
Complete real-time control
SEND EFFECTS
Wideshift Chorus
Saturator Delay
Supervoid Reverb
SYNTH VOICE (x4)
Completely analog signal path
2× analog oscillators
Variable waveshape on all waveforms
Oscillator AM and Sync modes
2× sub-oscillators
1× noise generator
1× 4-pole analog lowpass ladder filter
1× 2-pole analog multi-mode filter
1× analog overdrive circuit
Filter feedback
2× assignable LFOs
1× dedicated vibrato LFO
2× dedicated waveshape LFOs
1× amp envelope
2× assignable envelopes
2× dedicated LFO fade envelopes
1× dedicated noise fade envelope
1× dedicated vibrato envelope
1× dedicated autobend envelope
3x individual effect sends
MIDI control
FEATURES
Up to 4-Note Polyphony/Multitimbral/Unison
Dynamic voice allocation for the 4 tracks
+Drive enables multiple (x128) projects
ELECTRICAL SPECIFICATIONS
Impedance balanced audio outputs:
Main outputs level: +19 dBu
Output impedance: 440
 unbalanced
Headphones output:
Headphones out level: +19 dBu
Output impedance: 55

Unbalanced audio inputs:
Input level: +19 dBu maximum
Audio input impedance: 9 k
Digital S/N ratio: 102 dBFS (20-20.000 Hz)
Stereo Separate Track Outputs:
Output level: +19 dBu
Output Impedance: 1.2 k
Acceptable power supply: 100-250 VAC, 50-60 Hz
Unit power consumption: 14 W typical, 25 W maximum.
Power inlet type: IEC 60320 C8
Recommended power cable type: IEC 60320 C7, rated for
240V and at least 2.5A
HARDWARE
122x32 pixel backlit LCD
MIDI In/Out/Thru with DIN Sync out
2 x 1/4” impedance balanced audio out jacks
2 x 1/4” audio in jacks
1 x 1/4” stereo headphone jack
2 x 1/4” dual CV/Gate outputs
4 x 1/4” stereo (TRS) individual track outputs
37-key semi-weighted, velocity sensitive Keyboard with
aftertouch
Assignable omnidirectional joystick
48 kHz, 24-bit D/A and A/D converters
Flash-EEPROM upgradable OS
Electrically isolated USB 2.0 port
PHYSICAL SPECIFICATIONS
Aluminum casing
Dimensions: W660xD309xH93mm (26.0x12.2x3.7”)
(including audio outputs, knobs and rubber feet)
Weight: approximately 5.4 kg (11.9 lbs)




