The following table shows the relation between the settings of the jumpers 5…8 of JP1 and the
corresponding preset:
Jumper # Midi function of ... Preset
# 5 6 7 8 ST1 ST2 ST3 ST4 ST5
1 PIT MOD VOL AT SUST
2 PIT MOD VOL BC (*) SUST
3 VOL VOL+1 VOL+2 VOL+3 SUST
4 MOD 68 VOL EXP SUST
5 1/2 3/4 5/6 7/8 SUST
6 SUST SOST SOFT VOL SUST
7
8
9
10
11
12
13
14
15
16 PAN EXP VOL BAL SUST
5 = jumper installed
The factory setting is shaded grey (preset # 1).
Abbreviations:
PIT pitch bend
AT monophonic after touch
MOD modulation (control change # 1)
BC (*) breath control (control change # 2), voltage range adapted to BC2 (+5...+2,5V)
VOL volume (control change # 7)
BAL balance (control change # 8)
PAN panorama (control change # 10)
EXP expression (control change # 11)
SUST sustain (control change # 64)
SOST sostenuto (control change # 66)
SOFT soft pedal (control change # 67)
number other controller (number = control change number)
Remarks:
•
Preset #1 is the standard preset for pitch bender, modulation wheel and two controllers for
volume and after touch.
•
Preset #2 is similar to preset #1 but after touch is replaced by breath control. The WE
firmware has been adapted to the Yahama BC2. Provided that the BC2 is wired as
described on page 9 it generates a voltage in the range of +5V (no pressure) to ~ +2,5V
(maximum pressure), i.e. the behaviour is reverse (higher pressure
→ lower voltage) and the
voltage range is limited to about +2,5...+5V. In preset #4 connector ST4 has been adapted
to this reverse behaviour.
•
Preset #3 is planned to control the volume on four succeeding Midi channels. The Midi
channel selected by the jumpers 1...4 is valid only for ST1. ST2, ST3 and ST4 transmit their
volume data on the following Midi channels (marked by V+1, V+2, V+3).
• Preset #4 is a special preset for the organ emulation B4 by Native Instruments. The control
change numbers 1 (actually modulation) and 68 are used to control the rotary speakers.
