71 PJ Series
ITEM LIST - PJ SERIES
Part numbers are not provided in this manual. See CD (BLN-51427) for part numbers.
No. Description
1 Housing Kit
2 End Cap Kit (W/Poppets, Standard Charge)
End Cap Kit (W/ SCR’S, Standard Charge)
End Cap Kit (W/ Poppets, Auxiliary Charge)
End Cap Kit (W/ SCR’S, Auxiliary Charge)
End Cap Kit (STD CHG) LH;SCR/HR: Poppet
End Cap Kit (STD CHG) LH:Poppet/RH:SCR
End Cap Kit (STD CHG) LH:SCR/RH:SCR
End Cap Kit (AUX CHG) LH:SCR/RH:Poppet
End Cap Kit (AUX CHG) LH:Poppet/RH:SCR
End Cap Kit (AUX CHG) LH:SCR/RHPoppet, Thru
End Cap Kit (AUX CHG) W/Poppets, Thru
End Cap Kit (AUX CHG) W/SCR;s, Thru
End Cap Kit (AUX CHG) LH:Poppet/RH:SCR, Thru
3 Straight Headless Pin
4 Hex Flange Bolt M8-1.25 X 60 mm LG
5 Housing O-Ring
6 Charge Pump Kit (STD)
Charge Pump Kit (STD CHG), Thru
Aux Pump Kit (AL., 15T Splined, 2-7/16 SAE
Ports)
Aux Pump Kit (AL., 15T Splined, 3-7/16 SAE
Ports)
7 STD Gerotor Assy (.11 cu. In/rev D-Drive)
Auxiliary Gerotor & Housing Assembly
8 O-Ring
10 Socket Head Screw M6 x 1.0-20 mm Lg (STD
CHg)
Hex Flange Bolt 8M-1.25 x 60 mm (Aux Chg)
Cap Screw, Hex 5/16-18 x 1.00 (Thru Chg)
Supplied with item # 2 only
15 Bypass Valve Kit (Blank)
Bypass Valve Kit (0.031”)
Bypass Valve Kit (0.043”)
18 Pump Shaft Kit (Blind 15mm Keyway
W/Std Chg)
Pump Shaft Kit (Blind 15mm Keyway
W/Aux Chg)
Pump Shaft Kit (9 Tooth W/Std Chg)
Pump Shaft Kit (9 Tooth W/Aux Chg)
Pump Shaft Kit (15mm Keyed, Std Chg, Thru)
Pump Shaft Kit (9 Tooth Thru Chg)
Pump Shaft Kit (Tapered)
19 Ball Bearing 17 X 40 X 12
20 Lip Seal 17 X 40 X 7 PTC
21 Spacer
22 Retaining Ring
25 Cylinder Block Kit
29 Block Spring
30 Block Thrust Washer
32 Swashplate
No. Description
34 Ball Thrust Bearing
35 Stud, Torque
37 Trunnion Arm
Trunnion, RTN
38 Slot Guide
42 Check Valve Kit (blank Orifice)
Check Valve Kit (0.024” Orifice)
Check Valve Kit (0.031” Orifice)
Check Valve Kit (0.044” Orifice)
System Check / Relief Kit
System Check Relief Kit (.031” Orifice)
Shock Valve Kit
44 Charge Relief Valve Kit (1/4” Plastic Ball
& 50654 Spring)
Charge Relief Valve Kit (9/16” SAE Plug
& 3101536 Spring)
45 Aux Relief Valve Kit (1/4” Steel Ball)
Aux Relief Valve Kit (Aux Poppet)
49 Trunnion Seal/Retainer Kit
54 Auxiliary Filter Kit
55 Plate, Adapter (Gear A)
56 Straight Thread Plug
59 O-Ring
64 Connector
66 5/16” SAE Plug
67 Filter Cover
69 Straight Headless Pin
75 Shim - Charge Pump (.002 - Red)
80 Pin, Straight Headless
85 R-Ring - 144
90 Hub / 6” Fan Kit
Hub / 7” CCW Fan Kit
Hub / 7” CW Fan Kit
Hug / 7” Fan Kit
98 Return Arm
99 Inner Scissor Arm
100 Seal Kit
101 Spacer RTN
102 Spring, Extension
103 Screw, 5/16 x .875 (patch)
104 Washer .34 x .88 x .06
105 Washer, Nylon
106 Bolt
107 Nut, Hex Lock 5/16 - 24 UNF
110
Kit, RTN, STD
Kit, RTN, CW
Kit, RTN, CCW
209 Shroud Bracket
210 Shroud
