22 PC Series
Miscellaneous 3/8-Inch Drive Ratchet and Sockets
P Series Service & Repair Manual 7/16-inch Socket
Torque Wrench 1/2-Inch Socket
Scribe, Paint Pen, or Marker 11/16-Inch Socket
Seal Hook with a Magnet 10-mm Socket
Flat Blade Screwdriver Combination Wrenches
Pliers 7/16 Inch
Internal Snap Ring 1/2 Inch
Allen Wrenches 11/16 Inch
1/8 inch 10 mm
1/4 inch
TOOLS AND TORQUES
Table 1. Required Tools
Table 2. PC Pump Torque Values
Item # and/or Description
Case Drain (fitting torque)
System Port (fitting torque)
Inlet (fitting torque)
Fan Nut, Hex Lock 5/16-24 UNF
4, End Cap/Adapter Plate Bolts
10, Cap Screw
15, Bypass Valve
42A, 42B, Shock Valves/Check Plugs
44, System Charge Relief Kit (Aux Chg)
45, Aux Relief Valve Kit
56, Diagnostic Plug
66, Filter Cover Plug
67, Filter Cover
103, Screw 5/16 x .875
106, Nut, Hex Lock 5/16-24 UNF
164, Plug, Metal 7/16-20
Torque
200-250 lb-in (22.6-28.2 Nm)
370-470 lb-in (41.8-53.1 Nm)
200-250 lb-in (22.6-28.2 Nm)
120-160 lb-in (13.5-18.1 Nm)
180-220 lb-in (20.3-24.9 Nm)
180-220 lb-in (20.3-24.9 Nm)
110-130 lb-in (12.4-14.7 Nm)
180-240 lb-in (20.3-27.1 Nm)
180-240 lb-in (20.3-27.1 Nm)
180-240 lb-in (20.3-27.1 Nm)
84-120 lb-in (9.4-13.5 Nm)
55-85 lb-in (6.2-9.6 Nm)
200-275 lb-in (22.6-31.1 Nm)
200-240 lb-in (22.6-27.1 Nm)
180-220 lb-in (20.3-24.9 Nm)
84-120 lb-in (9.4-13.5 Nm)
