35
PC Series
ITEM LIST - PC SERIES
Part numbers are not provided in this manual. See CD (BLN-51427) for part numbers.
No. Description
1
Housing Kit
2
End Cap
4
Screw, Hex Flange, M8 x 1.25
5
Housing O-Ring
6
Charge Pump Kit (Std. Charge)
Charge Pump Kit (Std. Charge) Thru
Shaft
7
STD Gerotor Assy (0.11 cu in./rev)
8
O-Ring
10
Cap Screw, Hex, 5/16 - 18 x 1.0
15
Bypass Valve Kit (No Bleed Orifice)
18
Pump Shaft Kit (1/2 in. Keyed w/Std.
Charge)
Pump Shaft Kit (1/2 in. Keyed, Thru
Shaft w Std. Charge
Pump Shaft Kit (9 tooth w/Std. Charge)
19
Ball Bearing, 17 x 40 x 12 mm
20
Lip Seal, 17 x 40 x 7 PTC
21
Spacer
22
Retaining Ring
23
Retaining Ring
25
Cylinder Block Kit
29
Block Spring
32
Swashplate
34
Ball Thrust Bearing
37
Trunnion Arm, Tapered Square
Trunnion
Arm, Double D
38
Slot Guide
42
Shock Valve Kit
2900 psi, (200 bar), No Orifice
2900 psi, (200 bar), 0.024 in. Orifice
2900 psi, (200 bar), 0.031 in. Orifice
2900 psi, (200 bar), 0.044 in. Orifice
2320 psi, (160 bar), No Orifice
2320 psi, (160 bar), 0.024 in. Orifice
2320 psi, (160 bar), 0.031 in. Orifice
2320 psi, (160 bar), 0.044 in. Orifice
1740 psi, (120 bar), No Orifice
1740 psi, (120 bar), 0.024 in. Orifice
1740 psi, (120 bar), 0.031 in. Orifice
1740 psi, (120 bar), 0.044 in. Orifice
No.
Description
44
Charge Relief Valve Kit (1/4 in. Plastic
Ball and 50654 Spring)
45
Auxiliary Relief Valve Kit
49
Trunnion Seal/Retainer Kit
54
Filter Kit
55
Plate, Adapter (Gear AA)
56
Plug, 5/16 - 24
66
Plug
67
Filter Cover
69
Pin, Straight Headless
80
Pin, Straight Headless
90
Fan Kit
100
Overhaul Seal Kit
101
Spacer, Return
102
Spring, Extension
103
Screw, 5/16 x 0.875 in. (PATCH)
104
Washer, 0.34 x 0.88 x 0.06 in.
105
Washer, Nylon
106
Nut, Hex Lock, 5/16 - 24 UNF
110
Return-to-Neutral Kit, Std.
Return-to-Neutral Kit, CW Scissor
Return-to-Neutral Kit, CCC Scissor
Return-to-Neutral Kit,
209
Shroud Bracket
210
Shroud
