Page 11
6
P Series
Figure 4. Pr Pump With Standard charge Pump
eXternal FeatureS - Pr SerIeS
TRUNNION ARM
INPUT SHAFT
CHARGE PRESSURE
DIAGNOSTIC PORT
“A” and “B” PORTS
INLET
BYPASS VALVE
CASE DRAIN
CHARGE
COVER
CASE DRAIN
SYSTEM CHECK VALVE
OR SHOCK VALVE
SYSTEM CHECK VALVE
OR SHOCK VALVE
SAE “A” PAD
FLANGE STYLE
BYPASS
VALVE
