38 PG / PE Series
TOOLS ANd TORQUES
Table 1. Required Tools
Table 2. PG / PE Pump Torque Values
Miscellaneous
P Series Service & Repair Manual
Torque Wrench
Scribe, Paint Pen, or Marker
Seal Hook with a Magnet
Flat Blade Screwdriver
Pliers
Internal Snap Ring
Allen Wrenches
5mm
3/16 inch
1/4 inch
3/8-Inch drive Ratchet and Sockets
1/2-inch Socket
9/16-inch Socket
5/8-inch Socket
10-mm Socket
Combination Wrenches
1/2 inch
9/16 inch
5/8 inch
7/8 inch
10 mm
Item # and/or description
Case Drain (fitting torque)
System Port (fitting torque)
Inlet (fitting torque)
Fan Nut, Hex Lock 5/16-24 UNF
4, End Cap Bolts
10, Cap Screw (Aux Pump and Shroud Bracket)
10, Cap Screw (Charge Pump Cover)
15, Bypass Valve
42A, 42B, Shock Valves/Check Plugs
44, System Charge Relief Kit (Aux Chg)
45, Aux Relief Valve Kit
56, Diagnostic Plug
66, Filter Cover Plug
67, Filter Cover
95, Screw, Socket Head Set
103, Screw 5/16 x .875
106, Bolt
107, Nut, Hex Lock 5/16-24UNF
Torque
200-250 lb-in (22.6-28.2 Nm)
370-470 lb-in (41.8-53.1 Nm)
200-250 lb-in (22.6-28.2 Nm)
180-220 lb-in (20.3-24.9 Nm)
180-220 lb-in (20.3-24.9 Nm)
180-220 lb-in (20.3-24.9 Nm)
87-118 lb-in (9.8-13.3 Nm)
84-120 lb-in (9.4-13.5 Nm)
180-240 lb-in (20.3-27.1 Nm)
180-240 lb-in (20.3-27.1 Nm)
180-240 lb-in (20.3-27.1 Nm)
84-120 lb-in (9.4-13.5 Nm)
55-85 lb-in (6.2-9.6 Nm)
200-275 lb-in (22.6-31.1 Nm)
100-185 lb-in (11.3-20.9 Nm)
200-240 lb-in (22.6-27.1 Nm)
180-220 lb-in (20.3-24.9 Nm)
180-220 lb-in (20.3-24.9 Nm)
