Hydraulic schematic – Cub Cadet ZT-3400 User Manual
Page 5
ZT-2800
®
/ZT-3100/ZT-3400™
3
ZT-2800
®
3
figure 2, Hydraulic schematic without Charge pump (ZT-2800)
HYdraULiC sCHeMaTiC
figure 1, Hydraulic schematic with Charge pump
Vent
Vent
Bypass
Motor Shaft
Motor
Pump
Filter
Charge Pump
Charge Relief
System Check Valves
Input Shaft
Case Reservoir
Motor Shaft
System Check Valves
Input Shaft
Filter
Pump
Motor
Bypass
Case Reservoir
