1.1.2 Corner mount
Check the wall and make sure it’s firm. The bearing weight is more than 8 times of the
speed dome weight.
f. Label installation position a. Install the base
Make the power cable, RS485 cable and
video cable through the hole of base
g. Install the bracket b. The same way of wall mount
installation
1.1.3 Pole mount
The diameter of pillar is 130-150mm( 5.12”~6)
a. Install the base b. Install the bracket
c. The same way of wall mount
installation
1.1.4 Ceilling mount
If the ceiling is too low, we can install the speed dome on the base directly.
a. Label installation position c. Installation the base
