PELCO-P OFF ON OFF OFF OFF OFF
Fig 5.2
3.4. Setup of the Baud Rate of Communication
As shown of figure 5.1, J8 set the protocol and baut rate of speed dome. DIP-4to
DIP-1 to choose the protocol, max 4 selection of baut rate.If the baut rate of contrller isn’t
standard, please adjust the baut rate the same with it.
Baut rate
Bate rate set
DIP-1 DIP-2 DIP-3 DIP-4 DIP-5 DIP-6
2400bps OFF OFF
4800bps ON OFF
9600bps OFF ON
19200bps ON ON
3.5. Selection of the Terminal Resistor of the Dome Camera
As shown of figure 5.1,J6 is the select switch of the 120 Ω terminal resistor on
the bus RS485, on which only one terminal resistor of the dome camera at the
farthest end can be connected, while the terminal resistors of other devices
should be opened.
J6, the tenth turn to be ON:120 Ω terminal resistor is open; turn to be OFF: Ω
terminal resistor is closed.
4. Shortcut control function
Preset N Set Preset N Call Preset N
1 Reserved
Twice Call Preset 1 within 4
seconds Open the menu
63 Open camera menu Open camera menu
64 Close the menu Open the menu
90 Reserved Reserved
91 Reserved Run the first patrol
92 Reserved Scan limit to left
93 Reserved Scan limit to right
94 Reserved Reserved
95 Close the menu Open the menu
96 Reserved Stop scan
97 Reserved Run the first scan
