– 9 –

5.3 Setting a new Damping Factor

1. Press and hold the DAMP key. The display shows the set damping factor.

2. You can now increase the damping factor by pressing the MEM key and decrease it

by pressing the RECALL key.

3 Once the new factor appears on the display, release the DAMP key. The tension

meter switches back to measuring mode.

NOTE: The selected damping factor remains stored in the KXE memory even after the
instrument is switched off.

6.0 Memory Modes


The tension meter features a data
logger with a memory capacity for
up to 4000 readings, with which
you can store different measuring
periods at one or more machine
positions. The readings are saved 2x
per second, synchronously with the
display update rate, in all memory
modes except the “F” mode in which
they are saved 100x per second. All
saved readings and statistics can be
shown on the display or transmitted
to a PC (e.g. for further processing in Excel). The memory can be allocated to different
measuring periods, depending on the memory mode.

NOTE: The selected memory mode remains stored in the KXE memory even after the
instrument is switched off.

Memory mode “S” STANDARD (default)

The following values of a measuring period are calculated and saved at a rate of 2
readings per second:

Average value,
Last value,
Maximum value

(MAX),

Minimum value

(MIN),

Minimum peak value (MIN PEAK)
Maximum peak value (MAX PEAK)

Individual readings are not saved. You can save up to 255 measuring periods.

Memory Mode

S

C

L

F

Meas. periods,
max.

255

255

255

255

Readings, max.

4000

4000

4000

Max. no. of
readings per
position

Any

10

Any

Statistics

Yes

Yes

Yes

Yes

Save Readings

Yes

Yes

Yes

– 20 –

7. Press the RECALL key. The DISPLAY blinks, showing

฀฀฀฀฀฀฀฀฀฀฀฀฀26

Peak

the

maximum peak value (PEAK MAX) of the measuring period, the PEAK indicator

and the symbol

8. Press the RECALL key. The DISPLAY blinks,

฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀19

Peak

showing the

minimum peak value (PEAK MIN) of the measuring period, the PEAK indicator

and the symbol.

9. Press the RECALL key. The measured values no. 1 — 10 of the first measuring

period can be recalled.

10. Press the RECALL key. The next measuring period (POS: 2) is shown on the

DISPLAY and the sequence is repeated, starting with the average value (AVG).

8.4 Recalling the Stored Tension Values in Mode “F“ FAST

1. Tension meter switched on as described in Chapter 3.3.1.

2. Press the RECALL key.

NOTE: You can end recall any time by pressing the POWER key.

Memory Mode CONTINUOUS

Pos:

1

Pos:

12

Pos:

3

Pos:

4

AVG:

22.0

AVG:

12.0

AVG:

12.0

AVG:

12.0

Last:

23.0

Last:

22.1

Last:

22.1

Last:

22.1

MAX:

24.0

MAX:

22.1

MAX:

22.1

MAX:

22.1

MIN:

21.0

MIN:

5.4

MIN:

5.4

MIN:

5.4

PEAK

MAX

:

26.0

PEAK

MAX

:

28.1

PEAK

MAX

:

28.1

PEAK

MAX

:

28.1

PEAK

MIN

:

19.0

PEAK

MIN

:

1.8

PEAK

MIN

:

1.8

PEAK

MIN

:

1.8

10.8

14.2

14.1

15.4

10.0

19.4

11.2

18.3

7.3

22.9

8.9

17.5

6.1

17.3

10.2

7.8

n

n

n

n
