– 14 –
To stop data logging:
When you want to end the measuring period, press the MEM key once again. The
statistical values are calculated from the logged tension data and stored in the following
order:
Average value,
Last value,
Maximum value
(MAX),
Minimum value (MIN),
Minimum peak value (MIN PEAK),
Maximum peak value (MAX PEAK).
Tension Value - 1 -
Tension Value - 2 -
Tension Value - 10 -
(up to 10 tension values in up to 255 measuring periods)
The MEM
฀฀฀฀฀฀฀฀฀฀฀฀฀3฀฀
Mem indicator stops blinking and remains on the display. The
tension meter shows the current reading and changes back to measuring mode.
To save the next measuring period:
1. Press the MEM key again. The display shows the memory mode “L” and the next
memory number
฀฀฀฀฀L฀฀฀฀฀฀฀฀2
. You can save up to 255 measuring periods with a
maximum of 10 readings each.
7.4 Data Logging in Mode “F” Fast
1. Turn on the tension meter and select the “F” Fast Memory Mode as
described in Section 6.1.
2. Insert the process material as described in Section 4.1.
3. To save the first measuring period, press and hold the MEM key
฀฀฀฀฀฀฀F฀฀฀฀฀฀฀1฀฀
until the display shows the memory mode “L” and the current
memory number .
4. Release the MEM key. The tension meter starts logging data at the rate of 100
readings per second
While the tension data are stored, the MEM indicator blinks
฀฀฀฀฀฀฀฀฀฀฀฀฀3฀฀
Mem on the
display and the currently measured value is displayed.
– 15 –
To stop data logging:
When you want to end the measuring period, press the MEM key once again. The
statistical values are calculated from the logged tension data and stored in the following
order:
Average value,
Last value,
Maximum value
(MAX),
Minimum value (MIN),
Minimum peak value (MIN PEAK),
Maximum peak value (MAX PEAK).
Tension Value - 1 -
Tension Value - 2 -
Tension Value - N -
(up to 4000 tension values in up to 255 measuring periods)
The MEM
฀฀฀฀฀฀฀฀฀฀฀฀฀3฀฀
Mem indicator stops blinking and remains on the display. The
tension meter shows the current reading and changes back to measuring mode.
To save the next measuring period:
1. Press the MEM key again. The display shows the memory mode “F” and the next
memory number
฀฀฀฀฀F฀฀฀฀฀฀฀฀2
. You can save up to 255 measuring periods with a
maximum of 4000 readings.
8.0 Recalling the stored tension values
Using the TENSION INSPECT software included with your tension meter, you can
easily and accurately evaluate the stored tension values and export them to an Excel
sheet.
8.1 Recalling the Stored Tension Values in Mode “S“ STANDARD
1. Tension meter switched on as described in Chapter 3.2.
2. Press the RECALL key.
NOTE: You can end recall any time by pressing the POWER key.
