– 11 –
6.1 Memory Mode Selection
1. Turn on the tension meter and clear the memory by simultaneously pressing the
MEM and RECALL keys.
2 Press and hold the MEM key. The display shows S
฀฀฀฀฀฀฀฀฀฀฀฀฀S฀฀
. Press the
DAMP or RECALL key to change the memory mode.
MEMORY MODE “S” STANDARD (default)
฀฀฀฀฀฀฀฀฀฀฀฀฀S฀฀
If the display shows S. The STANDARD memory mode is set.
MEMORY MODE “C” CONTINUOUS
฀฀฀฀฀฀฀฀฀฀฀฀฀C฀฀
If the DISPLAY shows C, the CONTINUOUS memory mode is set.
MEMORY MODE “L” LIMIT
฀฀฀฀฀฀฀฀฀฀฀฀฀L฀฀
If the DISPLAY shows L , the LIMIT memory mode is set.
MEMORY MODE “F” FAST
฀฀฀฀฀฀฀฀฀฀฀฀฀F฀฀
If the DISPLAY shows F , the FAST memory mode is set.
When you have selected the desired memory mode, you can release the MEM key. The
selected memory mode is now active and the tension meter switches back to measuring
mode.
NOTE: The selected memory mode remains stored in the KXE memory even after the
instrument is turned off.
7.0 Data Logging
7.1 Data Logging in Mode “S” Standard
1. Turn on the tension meter and select the “S” Standard Memory Mode as described
in Section 6.1.
2. Insert the process material as described in Section 4.1.
3. To save the first measuring period, press and hold the MEM key
฀฀฀฀฀S฀฀฀฀฀฀฀฀฀฀1฀฀
until the display shows the memory mode “S” and the current
memory number .
4. Release the MEM key.
The tension meter starts logging the data.
– 18 –
5. Press the RECALL key. The DISPLAY blinks, showing
฀฀฀฀฀฀฀฀฀฀฀฀฀24
the
maximum value (MAX) of the measuring period and the symbol.
6. Press the RECALL key. The DISPLAY blinks, showing
฀฀฀฀฀฀฀฀฀฀฀฀฀21
the
minimum value (MIN) of the measuring period and the symbol.
7. Press the RECALL key. The DISPLAY blinks, showing
฀฀฀฀฀฀฀฀฀฀฀฀฀26
Peak the
maximum peak value (PEAK MAX) of the measuring period, the PEAK indicator
and the symbol
8. Press the RECALL key. The DISPLAY blinks,
฀฀฀฀฀฀฀฀฀฀฀฀฀฀฀19
Peak showing the
minimum peak value (PEAK MIN) of the measuring period, the PEAK indicator
and the symbol.
9. Press the RECALL key. The measured values no. 1 — n of the first measuring
period can be recalled.
10. Press the RECALL key. The next measuring period (POS: 2) is shown on the
DISPLAY and the sequence is repeated, starting with the average value (AVG).
