– 12 –
While the tension data are stored, the MEM indicator blinks
3
Mem
on the
display and the currently measured value is displayed
To stop data logging:
When you want to end the measuring period, press the MEM key once again. The
statistical values are calculated from the logged tension data and stored in the following
order:
Average value,
Last value,
Maximum value
(MAX),
Minimum value
(MIN),
Minimum peak value (MIN PEAK),
Maximum peak value (MAX PEAK).
The MEM
3
Mem
indicator stops blinking and remains on the display. The
tension meter shows the current reading and changes back to measuring mode.
To save the next measuring period:
1. Press the MEM key again. The display shows the memory mode “S” and the next
memory number
S2
. You can save up to 255 measuring periods.
7.2 Data Logging in Mode “C” Continuous
1. Turn on the tension meter and select the “C” Continuous Memory Mode as
described in Section 6.1.
2. Insert the process material as described in Section 4.1.
3. To save the first measuring period, press and hold the MEM key
C1
until the display shows the memory mode “C” and the current
memory number .
4. Release the MEM key. The tension meter starts logging the data.
While the tension data are stored, the MEM indicator blinks
3
Mem
on the
display and the currently measured value is displayed.
– 17 –
8. Press the RECALL key. The DISPLAY blinks,
19
Peak
showing the
minimum peak value (PEAK MIN) of the measuring period, the PEAK indicator
and the symbol.
9. Press the RECALL key. The next measuring period (POS: 2) is shown on the
DISPLAY, starting at the beginning of the sequence with the average value (AVG).
8.2 Recalling the Stored Tension Values in Mode “C“ CONTINUOUS
1. Tension meter switched on as described in Chapter 3.2.
2. Press the RECALL key.
NOTE: You can end recall any time by pressing the POWER key.
Memory Mode CONTINUOUS
Pos:
1
Pos:
12
Pos:
3
Pos:
4
AVG:
22.0
AVG:
12.0
AVG:
12.0
AVG:
12.0
Last:
23.0
Last:
22.1
Last:
22.1
Last:
22.1
MAX:
24.0
MAX:
22.1
MAX:
22.1
MAX:
22.1
MIN:
21.0
MIN:
5.4
MIN:
5.4
MIN:
5.4
PEAK
MAX
:
26.0
PEAK
MAX
:
28.1
PEAK
MAX
:
28.1
PEAK
MAX
:
28.1
PEAK
MIN
:
19.0
PEAK
MIN
:
1.8
PEAK
MIN
:
1.8
PEAK
MIN
:
1.8
10.8
14.2
14.1
15.4
10.0
19.4
11.2
18.3
7.3
22.9
8.9
17.5
6.1
17.3
10.2
7.8
n
n
n
n
3. The DISPLAY blinks, showing
22
the average value (AVG) of the first
measuring period (POS: 1) and the symbol.
4. Press the RECALL key. The DISPLAY blinks, showing
23
the
last value (LAST) of the measuring period.
