The Choose Analysis window
5. Click on the Define and Open New Configuration radio button
(or verify that the option is selected).
NOTE
If you have already configured and saved an analysis, its name will
appear in the list box on the right side of the window. If you click on an
existing configuration and click OK, the analysis will be performed using
the selected configuration settings. It will not be necessary to complete
the remaining steps in this procedure.
6. Click OK. The Sample Analysis Configuration window will
appear.
The Sample Analysis Configuration window consists of three
tabbed pages:
Date Filter—allows you to select date/time parameters for the
analysis
Sample Filter—allows you to select which tubes/technicians/tests
will be included in the analysis.
Report—allows you to select what sample data will appear in the
CAV Data Table and how the data will be displayed
7. Click on the tab corresponding to the filter you wish to set and
complete configuration options per the instructions below:
Date/Sample filters
Complete selection of Date/Sample filter options per the instructions
in Chapter 6.
