BUCHI Pump Module C-605 - Manual (Page 12)

3 Technical data
12 Pump Combinations Operation Manual, Version E
8
9
Table 3-6: Optional accessories
Product Order number
h Solvent valve set 44854
i System stand for pump module 44855
10
j Tubing fitting set 44021
11
k External pressure sensor without
mixing chamber. Needed only for very
pressure sensitive columns, enables
to measure direct at the column inlet.
54040
Glass column, 15/100 / Prep Elut 44030
Glass column, 26/100 / Prep Elut 44035
3 .2 Materials used
Table 3-7: Materials used
Component Material designation
Housing (Pump Manager, Pump Controller, Pump Module) PUR foam
Pump excenter housing
Aluminium
Housing C-620 Stainless steel
Pump head PEEK
Pump cover PP
Tubings FEP / 1 x silicone
Fitting POM
Valve screw fitting POM
Ferrule ETFE
Cone ring POM
Radial seal PTFE
Pistons Ceramic
