Nibblized Preset Data
Checksum (LSB)
Preset Trailer
0 1 0 0
0000
(40H)
Indicates end of a given preset
Padding
...
...
500 consecutive bytes of the
pattern 00H
Preset ID
0001
0000
(10H)
Nibblized Second Preset ID
(MSB)*
0001
0001
(11H)
Nibblized Second Preset ID
(LSB)*
Preset Data
...
...
112 consecutive bytes
containing info for one preset
Preset Checksum
0001
nnnn
‑
Nibblized Preset Data
Checksum (MSB)
0001
nnnn
‑
Nibblized Preset Data
Checksum (LSB)
Preset Trailer
0100
0000
(40H)
Indicates end of a given preset
Padding
...
...
500 consecutive bytes of the
pattern 00H
|
|
Preset ID
0001
0000
(10H)
Nibblized Last Preset ID (MSB)*
0001
1111
(1FH)
Nibblized Last Preset ID (LSB)*
Preset Data
...
...
112 consecutive bytes
containing info for one preset
Preset Checksum
0001
nnnn
‑
Nibblized Preset Data
Checksum (MSB)
0001
nnnn
‑
Nibblized Preset Data
Checksum (LSB)
Preset Trailer
0100
0000
(40H)
Indicates end of a given preset
Padding
...
...
500 consecutive bytes of the
pattern 00H
EOX
1111
0111
(F7H)
End of Exclusive
* ‑ Valid preset
range 0‑15
