A-16cs rear panel – Aviom A-16R/A-16CS User Manual
Page 25
16
A-16R P
eRsonAl
M
ixeR
And
A-16Cs C
ontRol
s
uRfACe
u
seR
G
uide
1
A‑Control In jack (rear panel)
2
A‑Net Active LED
3
Channel Pan control and LEDs
4
Channel Volume control and LEDs
5
Footswitch jack (rear panel)
6
Bass tone control
7
Treble tone control
8
Master volume control
9
Solo button
10
Mute button
11
Channel Mute LED
12
Channel select LED
13
Channel or Preset select button (depends on mode)
14
Label strip
15
Recall button (for Save, hold R
ecall
and G
Roup
)
16
Group button
Footswitch 1/2
A-Control
T-FtSw 1
R-FtSw 2
S-Ground
1
5
A-16CS Rear Panel
