Steffes 8188 - Manual (Page 27)

MODEL 8155
SPECIFICATIONS
Appendix
A
MODEL 8150
A PPENDIX
„
A.01 T HERM E LECT
* Optional 3000 CFM Air Handler increases approximate installed weight by 40 pounds.
Input Voltage 240 120/208 120/240 277/480 347/600
Phase 1 3 3 3 3
Number of Wires 2 3 3 4 4
Charging Input (kW) 53.3 48.0 53.3 50.4 53.3
Elements - Quantity
Elements - Watts Each 12
4,444
12
4,000
12
4,444
12
4,200
12
4,444
Amps – Core Charging 222.20 133.39 128.44 60.65 51.23
Max. Core & Blower Load (AMPS) 3.0 7.4 7.4 2.3 3.0
Minimum Circuit Ampacity 281.50 175.99 169.80 78.69 67.78
Blowers/System Control Voltage 240V/208V 240V/208V 240V/208V 240V/208V 240V/208V
Storage Capacity - kWh
Storage Capacity - BTU 320
1,091,840
Approximate Storage Module Weight (lbs) 770
Approximate Insulation Block, Air Handler,
Elements & Other Weight (lbs)
330 (utilizing 2000 CFM Air Handler)*
Approximate Brick Weight (lbs) 3,440
Approximate Installed Weight (lbs) 4,540 (add approx. 500 lbs to arrive at shipping weight)
Number of Brick 192
Input Voltage 240 120/208 120/240 277/480 347/600
Phase 1 3 3 3 3
Number of Wires 2 3 3 4 4
Charging Input (kW) 106.6 96.0 106.6 100.8 106.6
Elements - Quantity
Elements - Watts Each 24
4,444
24
4,000
24
4,444
24
4,200
24
4,444
Amps – Core Charging 444.40 266.79 256.88 121.30 102.46
Max. Core & Blower Load (AMPS) 3.0 7.4 7.4 2.3 3.0
Minimum Circuit Ampacity 559.25 342.73 330.35 154.50 131.82
Blowers/System Control Voltage 240V/208V 240V/208V 240V/208V 240V/208V 240V/208V
Storage Capacity - kWh
Storage Capacity - BTU 640
2,183,680
Approximate Storage Module Weight (lbs) 770 per module = 1,540 Total
Approximate Insulation Block, Air Handler,
Elements & Other Weight (lbs)
610 (utilizing 2000 CFM Air Handler)*
Approximate Brick Weight (lbs) 3,440 per module = 6,880 Total
Approximate Installed Weight (lbs) 9,030 (add approx. 600 lbs to arrive at shipping weight)
Number of Brick 192 per module = 384 Total
