PartS liSt
* If system was built prior to 2007, the Core Blower Assembly must be ordered.
** Optional voltages available. Contact dealer/distributor with model and serial number to order.
DWg.
rEF. DESCrIPTION 5120 5130 5140
NO. ITEM NO. ITEM NO. ITEM NO.
1A Electrical Panel Cover
(non-recessed breakers)
5940853 5940852 5940852
" Electrical Panel Cover (recessed breakers) 5940845 5940845 5940845
1B Filler, Painted Electrical Panel Cover 5940846 N/A N/A
2 Front Painted Panel 5940589 5940526 5940588
3 PCB Relay Expansion Board 1023067R 1023067R 1023067R
4 PCB Base I/O Relay Board 1023078R 1023078R 1023078R
5 Terminal Block 12 Position 1016040 1016040 1016040
" Terminal Block 6 Position 1016041 1016041 1016041
6 Transformer 75VA 1017039 1017039 1017039
7 PCB Processor Control Board 1023065R 1023065R 1023065R
8 Processor Control Boad Mounting Bracket 5940850 5940850 5940850
9 Breaker 15 Amp 1024000R 1024000R 1024000R
10 Breaker 60 Amp 1024002R 1024002R 1024002R
11 Breaker Standoff 5940868 5940868 5940868
12 Electrical Panel Insert Center 5940862 5940862 5940862
13 Electrical Panel Insert Left 5940864 5940864 5940864
14 Electrical Panel Insert Right 5940860 5940860 5940860
15 Harness, Breaker to Element Black 1041503 1041515 1041502
16 Harness, Relay to Element Red 1041701 1041713 1041700
17 Front Air Channel 5940820 5940822 5940824
18 Front Standoff 5940513 5940513 5940513
19 Front Galvanized Panel 5940579 5940524 5940578
20 Upper Brick Core Temperature Sensor N/A 1041725R 1041725R
" Lower Brick Core Temperature Sensor 1041725R 1041725R 1041725R
21 Core Blower Assembly 1041730R 1041730R 1041730R
" *Motor 1020010R 1020010R 1020010R
" *Wheel 1020002R 1020002R 1020002R
22 Pressure Relief Valve 1100104 1100104 1100104
23 Faceplate Label 1159029 1159029 1159029
24 Brick Tray 5940548 5940548 5940548
25 Insulation Block TR19 1054144 1054144 1054144
26 **Heating Elements 2400W 240V 1014021 1014021 1014021
" **Heating Elements 2850W 240V N/A N/A 1014250
" **Heating Elements 3100W 240V 1014024 1014024 N/A
27 Brick, Boxed 5903015 5903015 5903015
28 Right Side Core 5940559 5940557 5940558
29 Outdoor Sensor - Knockout Style 1302033 1302033 1302033
30 Right Side Painted Panel 5940587 5940525 5940586
31 Right Side Standoff 5940570 5940570 5940570
32 Micropore Insulation Panel 1050122 1050121 1050120
33 Top Painted Panel 5940590 5940590 5940590
34 Core Limit Jumper 1041510 1041510 1041510
When ordering parts, please include the system model and serial number.
