§1 MTS Broadcast/TV Stereo System
\\A
Check list before you begin.
□ All connections are made (see page 5).
Q Your Combination VCR is plugged in.
IMPORTANT NOTE:
This stereo system is designed
for TV viewing only. Recording
and piayback wiil always be in
monaural.
Receivable Broadcast Types
The following are possible broadcast types with their accompanying on-screen
displays. The signal being received is indicated with an “ [Cc" mark while the
selected audio mode is indicated with an arrow. To change the audio mode for
these broadcasts, follow the “Select Audio Mode for TV Viewing" section (below).
Push DISPLAY to display the broadcast signal
currently being received and the selected
audio mode.
MTS Stereo and SAP broadcast
Multi-channel Television Sound Stereo
(main language) and Secondary Audio
Program (sub language) broadcasts are
being received simultaneously. Select the
STEREO or SAP audio mode as desired.
STOP 12:00AM WNET
0
:
0 0 : 0 0
(itSTEREO «- SLP
(i$AP
MONO
MTS Stereo broadcast
Multi-channel Television Sound Stereo
broadcast is being received. Select the
STEREO audio mode.
• If a stereo broadcast is weak and the
display flickers, you may want to select
the MONO audio mode for better results.
SAP broadcast
Secondary Audio Program (sub language)
broadcast is being received. Select SAP
audio mode for the sub language.
MONO broadcast
Normal monaural sound broadcast is being
received.
STOP 12:00AM WNET
0:00:00
^STEREO <- SLP
SAP
MONO
STOP 12:00AM WNET
0:00:00
STEREO SLP
(iSAP <-
MONO
STOP 12:00AM WNET
0 :0 0 : 0 0
STEREO SLP
SAP
MONO <-
Select Audio Mode for TV Viewing
Push AUDIO to select the desired audio mode
as described above. (Arrow shows selection.)
• Each push of AUDIO will change the audio mode as
shown below.
38
< Example >
.Push
AUDIO
STOP 12:00AM
»■STEREO *r
SAP
MONO
WNET
0:00:00
SLP
LPush
AUDIO
STOP 12:00AM WNET
0 : 0 0 : 0 0
»STEREO SLP
SAP <-
MONO
LPush
AUDIO
STOP 12:00AM WNET
0
:
0 0 : 0 0
»STEREO SLP ^AP
MONO
