Removing Thermal Head Protective Sheet and ADF Protective Sheet

1. Press down on the latch button on the right side of the cover and open the Receiving Unit.

(1) Remove the Head Protective Sheet.

(2) Close the Receiving Unit down until the cover locks into position, you will hear a "click" sound.

Head Protective
Sheet

Latch Button

(3) Unlock the ADF unit by gently pulling up both sides of the ADF. Remove the ADF Protective

Sheet and then lock the ADF unit by gently pressing down on both sides of the ADF.

ADF Protective Sheet
