USING THE GRAPHIC EQUALIZER

The MT120S has a stereo 5-band graphic equalizer built in. As the block diagram below makes clear, signals assigned to

the left and right channels by the PAN control and level adjusted using the MASTER fader are sent to the equalizer.

Therefore, It can be used during ping-pong recording, mixdown operation and when recording with the REC SELECT control

set to “L” or “R.” The equalizer cannot be used when the REC SELECT control is set to “1”

—

“4,” however, since each

channel signal is recorded directly on the appropriate track.

The graphic equalizer affects only the signal paths marked with bold lines in the diagram below.

(MONO)

AUX
RETURN

AUX

RETURN

MIC/UNE

INPUT

SELECT

r 4 <

INPUT
FADER

PAN

TRACK

1,3

TRACK

2,4

■ 0-:

REC

SELECT

MASTER
FADER

GRAPHIC
EQUALIZER

GRAPHIC

EQUALIZER

AUX SEND

MONITOR

1 ,3

SELECT

REC

SELECT

MONITOR

2,4

SELECT

MONITOR /
PHONES

MONITOR/
PHONES

STEREO OUT

AUXSEND

TAPE OUT

MONITOR OUT

-o—

PHONES

MONITOR OUT

M T 1 2 0 S M U L T I T R A C K C A S S E T T E R E C O R D E R
