CINEMA-DSP
CINEMA-DSP programs
■ For movie programs: No. 7 to 9
This unit automatically chooses the appropriate decoder and DSP sound field pattern according to the input signal
format.
Table of Program Names for Each Input Format
N. Input
2 channel
5.1 channel
6.1 channel *
No.
Program
Stereo
DOLBY DIGITAL
DTS
DOLBY DIGITAL
Matrix 6.1
DTS
Matrix 6.1
7
MOVIE
THEATER 1
70 mm spectacle
DGTL Spectacle
DTS Spectacle
Spectacle 6.1
Spectacle 6.1
70 mm Sci-Fi
DGTL Sci-Fi
DTS Sci-Fi
Sci-Fi 6.1
Sci-Fi 6.1
8
MOVIE
THEATER 2
70 mm Adventure
DGTL Adventure
DTS Adventure
Adventure 6.1
Adventure 6.1
70 mm General
DGTL General
DTS General
General 6.1
General 6.1
9
DOLBY
DIGITAL
—
Normal
—
Matrix 6.1
—
—
Enhanced
—
Enhanced 6.1
—
DTS DIGITAL
SUR
—
—
Normal
—
Matrix 6.1
—
—
Enhanced
—
Enhanced 6.1
PRO LOGIC
Normal
—
—
—
—
Enhanced
—
—
—
—
PRO LOGIC
n
Movie
—
—
—
—
Music
—
—
—
—
^ means the Matrix 6.1 decoder is ON.
\i/
• If a Dolby Digital signal or DTS signal is input when the input mode is set to AUTO, the DSP program will automatically switch to
the Dolby Digital playback sound field or DTS playback sound field.
• If Dolby Digital Surround EX software or DTS ES software is played when AUTO is selected by pressing the MATRIX 6.1 button
on the remote control, the Dolby Digital + Matrix 6.1 or DTS + Matrix 6.1 decoder usually turns on and the corresponding DSP
program is selected.
• MATRIX 6.1 on the remote control can be used to play Dolby Digital or DTS 5.1 channel sources with the virtual rear center
speaker. In this case the program name changes to the corresponding name for 6.1 channel.
• When playing a 6.1 channel source with MATRIX 6.1 on the remote control turned off, the program name changes to the
corresponding name for 5.1 channel.
Notes
'
The “ i DSP ] ” indicator does not light up when selecting program No. 9 except in Enhanced mode.
’ When playing a monaural source with a CINEMA DSP program, the source signal is directed to the center channel, main and rear
speakers output effect sounds.
