Nortel Secure Router 8000 Series
Troubleshooting - VAS__________
2 IPSec and IKE troubleshooting
Interface: Ethernet4/2/0
path MTU : 1500
IPsec policy name: "map1"
sequence number: 10
mode: isakmp
connection id: 37
encapsulation mode: transport
tunnel local : 202.38 .163.1 tunnel remote: 202.38.162.1
[inbound ESP SAs]
sp^: 2940433602 (0xaf4374c2)
proposal: ESP-ENCRYPT-DES ESP-AUTH-SHA1
sa remaining key durat^ion (bytes/sec): 1887436496/708
max received sequence-number: 4
udp encapsulation used for nat traversal: N
[outbound ESP SAs]
sp^: 3424984209 (0xcc251c91)
proposal: ESP-ENCRYPT-DES ESP-AUTH-SHA1
sa remaining key duration (bytes/sec): 1887436448/708
max sent sequence-number: 5
udp encapsulation used for nat traversal: N
You can also use the display ipsec sa brief command to display brief information about
IPSec SAs.
Src Address Dst Address SPI
Protocol Algorithm
202.38.162.1
202.38.163.1
1918468181
ESP
202.38.163.1
202.38.162.1
1156810487
ESP
E:DES; A :HMAC-SHA1-96;
E:DES; A :HMAC-SHA1-96;
If SA setup in Phase 2 fails, the reasons are as follows:
•
IPSec proposals or IPSec policies configured on the peer are mismatched.
•
ACLs at two ends are not mutually mirroring.
You can use the display ipsec proposal name command and the display ipsec policy name
command on two ends to view IPSec proposals and policies and check whether ALCs are
mutually mirroring.
For more information, see “Troubleshooting manual IPSec SA setup .”
If the SA is set up successfully in Phase 2, continue with the following steps.
Step 4 Check whether IPSec can encapsulate or decapsulate packets based on the SA.
Use the debugging ipsec packet command to view IPSec packet encapsulation and
decapsulation. You can also use the display ipsec statistics command to view IPSec statistics.
the security packet statistics:
input/output security packets : 56/56
input/output security bytes: 4816/5600
input/output dropped security packets: 0/2
