4 NAT troubleshooting
Nortel Secure Router 8000 Series
_________ Troubleshooting - VAS
Item
Description
Configuring the limit on the
number of connected users, the
traffic, and the total amount of BT
The maximum number of both users and source IP
addresses is 7.
4.2.3 Troubleshooting flowchart
In the networking environment described earlier, if the external user still cannot access the
internal server, or the internal user cannot access the external server after you configure NAT,
follow the troubleshooting procedures shown in Figure 4-5 .
4-6
Nortel Networks Inc.
Issue 01.01 (30 March 2009)
