Point Coding
Point coding allows to record point related codes with up to eight
attributes.
The input of point codes is possible in the following dialogs:
• in the main measurement dialog, if point code and attributes
have been defined in the display mask.
• in the measurement dialog of some of the TPS1100 application
programs. The programs must be configured to use the user
display mask and the display mask must contain point code and
attributes.
The point codes and attributes are recorded together with the
target point data (with the function keys REC or ALL).
Note: point code and attributes will be recorded only if defined so in
the REC-Mask.
Point codes can be entered manually or selected from a codelist
containing predefined point codes.
Such a codelist can be created with the PC-software “Codelist
Manager”. Please refer to the on-line help of the Leica SurveyOffice
Software for more information.
