Measure and record

The dialog “Measurement & Record” can be called directly from the
main menu or is displayed after the setup procedure.

Angles and distances can be measured and recorded with the
following measurement functions.

One keystroke for measuring angles and distance, and for
recording measurement data according to the selected REC-mask.

To record displayed angles according to the selected REC-mask.

To measure a distance and to display the measured distance.

To record displayed distance and angles according to the selected
REC-mask.

ALL key

REC key

DIST and REC
combination

MEAS\ Measurement & Record

Point Id

123

Refl. Ht. :

1.700 m

222.3444 g

82.3467 g

Horiz.Dist :

----- m

Elev.Diff. :

----- m

ALL

DIST

REC

SetHz >DISP

ALL

REC

DIST
