Lock the TCA/TCRA to the
prism
With the RCS1100 controller you can use the instrument
measurement functions as if you were using the instrument itself.
PROG\ Program selection
1 Free Station
MC
Switch on RCS mode.
Once the RCS mode has been activated, the lock mode on
instruments with ATR is switched on automatically, but the
instrument is not locked to the prism yet.
If you are at the station, you can manually aim to the prism and
trigger a distance measurement with DIST. The icon is
displayed as soon as the instrument is locked to the
prism.
If you are at the reflector pole, several search modes are available
to lock the instrument to the prism. Call the PROG fixed key to
access the RCS search modes.
Measure with RCS
F6
RCS+
COMPS PS JSTCK WORK+ LAST RCS+
Hz/V WORKA QUIT
