PowerSearch is an option for the TPS1100plus series that enables
the instrument to find a prism at any desired position within a short
period of time. When PowerSearch is activated, the instrument
starts to rotate around its standing axis. The transmitter emits a
vertical laser swath. If the laser swath detects a prism, the rotation
of the instrument is stopped. Afterwards a fine aiming in vertical
direction is performed by the ATR.
Search modes
• If no working area has been defined, then the instrument rotates
360° around its standing axis and PowerSearch scans the entire
horizon.
• If a working area is defined and activated then PowerSearch
only scans within the defined limits.
PowerSearch
Introduction
