Text mode
Original mode

Select a function from a
menu

Standard method

Quick method

You can select a function from a menu using the standard or the
quick method.
The example below shows how to select the function
“Configuration” from the main menu dialog.

To scroll the cursor bar until the function “Configuration” is
highlighted.
To confirm the selection and start the function.

Press the corresponding numeric key

to select and start the

function “Configuration”.

For long menus with 10 items or more, both digits displayed
in front of the function must be entered.

SETUP MEAS

MAIN MENU

1 Job Management

2 Data job Management

3 Codelist Management

4 Data Conversion

5 Configuration

6 Instrument Calibration

SETUP MEAS
