AAAAAAAA * ALE address to review scores for.
### * Channel number
T Transmit signal scores
SS SINAD score
BB Bit error rate
R Received signal scores
CC Combined score for this channel
* Cursorable fields
SYSTEM PROGRAM
This page provides access to the ALE database. The second line
presents a list four sub-page types where the ALE database can be
reviewed or modified. The up and/or down arrows on the second line
indicate that there is a list of items to choose from. The cursor is
placed on the second line by moving the cursor with the CRSR knob.
With the cursor on the second line the VAR knob is used to make the
desired selection then the ENT key is pressed to enable the selec-
tion. The sub-pages return to this page when the CLR key is pushed
to exit the page.
Operation
3-27 KHF 950/990 Pilots Guide
Rev. 0
Dec/96
SYS Program
}PPPPPPPPPPPP
Figure 3-33 System Program
AAAAAAAAAA Ch###
TSS:BB RSS:BB CC
Figure 3-32 LQA Score Page
