Wireless USB A/V Adapter Set User Guide
Page 24
 When dragging a running process window such as a movie or other application from the
main screen to the extended screen, it is recommended to pause or stop the running
application first, and restart it in the extended screen.
5.3.2 Configuring the Display via Windows Display Properties in Windows
XP/Vista
Display settings can also be configured from the Windows Display Properties dialog box. (In
Windows Vista: right click on the desktop, select Personalize > Display Settings . In
Windows XP: right click on the desktop, select Properties>Settings tab).
Figure 14: Windows Display Settings
5.3.2.1 Selecting the Correct Display Monitor
In the monitor drop down box, find the entry for the A/V Adapter display monitor "... on
DisplayLink Graphics ". You can arrange this display's position with respect to the other
monitors on the extended desktop by using the drag area at the top of the Windows Display
Settings dialog. If you are not sure which number represents which display, click
Identify
Monitors and a large identifying number will appear on each display.
5.3.2.2 Setting the Display to Extend or Mirror Mode
To set the display in Extend mode, check the option Extend the desktop onto this monitor
To set the display into Mirror mode, uncheck the box marked Extend the desktop onto this
monitor (see circle #1 in Figure 14).
Drag area for
selecting and
positioning display
