WEBS-MT/R Tower Installation Instructions
Copyright 2011 Talk-A-Phone Co. All rights reserved.
Page 4 of 8
Talk-A-Phone Co.
• 7530 North Natchez Avenue • Niles, Illinois 60714-3804
Phone 773.539.1100 • Fax 773.539.1241 • [email protected] • www.talkaphone.com
All prices and specifications are subject to change without notice.
Talk-A-Phone, Talk-A-Lert, Scream Alert and WEBS are registered trademarks of Talk-A-Phone Co.
Table 1. WEBS-MT/R DIN Rail Terminal Block Connections.
Terminal
# (Side A)
Connection
Terminal
# (Side B)
Connection
1
Emergency Phone AUX. Output # 1
30
Auxiliary Device Trigger Wire
2
Emergency Phone AUX. Output # 1
31
Auxiliary Device Trigger Wire
3
Emergency Phone AUX. Output # 2
32
LED Blue Light [Orange]
4
Emergency Phone AUX. Output # 2
33
LED Blue Light [Black]
5
Emergency Phone AUX. Output # 3
34
Auxiliary Device Trigger Wire
6
Emergency Phone AUX. Output # 3
35
Auxiliary Device Trigger Wire
7
WEBS-VCU
— 12 VDC Trigger [Orange]
36
Paging Amplifier
—12 VDC Trigger [Orange]
8
WEBS-VCU
— Ground [Black]
37
Paging Amplifier
— Ground [Black]
9
Local Paging Microphone
— 12 VDC
[White]
38
WEBS- VCU [Microphone Input]
— 12 VDC
[White]
10
Local Paging Microphone
— 12 VDC
Trigger [Green]
39
WEBS- VCU [Microphone Input]
— 12 VDC
Trigger [Green]
11
Local Paging Microphone
— Audio(+)
[Red]
40
WEBS-VCU [Microphone Input]
— Audio (+)
[Red]
12
Local Paging Microphone
— Audio(-)
[Black]
41
WEBS- VCU [Microphone Input]
– Audio (-)
[Black]
13
WEBS-CM-2 / VOIP-500 / WEBS-ZPS
—
12 VDC Trigger [Green]
42
WEBS- VCU [WEBS-CM-2 / WEBS-ZPS
Input]
— 12 VDC Trigger [Green]
14
WEBS-CM-2 / VOIP-500 / WEBS-ZPS
—
12 VDC [White]
43
WEBS- VCU [WEBS-CM-2 / WEBS-ZPS
Input]
— 12 VDC [White]
15
WEBS-CM-2 / VOIP-500 / WEBS-ZPS
—
Audio (+) [Red]
44
WEBS- VCU [WEBS-CM-2 / WEBS-ZPS
Input]
— Audio (+) [Red]
16
WEBS-CM-2 / VOIP-500 / WEBS-ZPS
—
Audio (-) [Black]
45
WEBS- VCU [WEBS-CM-2 / WEBS-ZPS
Input]
— Audio (-) [Black]
17
WEBS-ZPS
— Bare Shield [Yellow]
46
WEBS- VCU [WEBS-CM-2 / WEBS-ZPS
Input]
— Bare Shield [Yellow]
18
Not Used
47
WEBS-CM-2
– 12 VDC Power (-) [Black]
19
Not Used
48
Face Plate Light
– 12 VDC Power (-) [Black]
20
Not Used
49
21
Not Used
50
Paging Amplifier
– 12 VDC Power (-) [Black]
22
Not Used
51
WEBS-VCU / Paging Amplifier Shield
23
Power Supply / Battery
— 12 VDC (-)
[Black]
52
WEBS-VCU
– 12 VDC Power (-) [Black or
Green]
24
Connect to GROUND
53
GROUND
25
Power Supply / Battery
— 12 VDC (+)
[Red or White]
54
WEBS-VCU
— 12 VDC Power (+) [Red or
Brown]
26
Not Used
55
Paging Amplifier
— 12 VDC Power (+) [Red
or White]
27
Not Used
56
28
Not Used
57
Face Plate Light
— 12 VDC Power (+) [Red]
29
Not Used
58
WEBS-CM-2
— 12 VDC Power (+) [Red]
