No.2 – OFNA Racing Jammin X2 Truggy User Manual

Page 9

ASSEMBLY OF THE FRONT SHOCK STAY

ASSEMBLY OF THE KNUCKLE ARMS

ASSEMBLY OF THE KNUCKLE ARMS INTO FRONT LOWER ARMS

Step 2

Step 4

94009
4x10mm
Hex Screw

.....x4

Step 1

Step 2

94003
3x10mm
Hex Screw

.....x4

41009
3x28mm
Cap Screw

.....x2

41010

41035

41009

3x10mm

4x10mm

40527
Knuckle Arm
Bushing

.....x2

.....x4

.....x2

40528
King Pin Screw

Assemble both right and left sides

94042
4mm
Nylon Nut

36055
2.5x16.8mm
Pin

94034
4x4mm
Set Screw

40527

40528

4mm

40536

4mm

36053

40570

rew

40657

40526

36055

4x4mm

Step 3

Step 1

94041
3mm
Nylon Nut

.....x2

.....x1

4x10mm

40604

40668

3mm

40602
(Short)

94042
4mm
Nylon Nut

.....x2

4mm

36870
4x10mm
Set Screw

.....x2

40691

41009

Assemble both right and left sides

*A 4x10mm set screw is used
to adjust ride-height.

4x10mm
Set Screw

NO.2

BAG

NO.2

BAG

NO.2

BAG

Approx 2mm

Tighten

30776
4x10mm Washer

30776

Insert two 30776 washer
into arm shaft before
assembly.
