25

26

27

9

ASSEMBLY OF THE REAR SUSPENSION ARMS

Assembly for both right and left side.

ASSEMBLY OF THE REAR STABILIZER
RODS

94035
3x8mm
Set Screw

.....x2

94022
3x18mm
Hex Screw

.....x2

Makes two rods for left
and righthand-side.

3x8mm

40540

40540

30403

30341

3x18mm

94008
3x25mm
Hex Screw

.....x2

55 mm

Use this ball end on the wheel side.The left and right
hand side are the same. (Note the cut out.)

94005
3x16mm
Hex Screw

.....x2

94041
3mm
Nylon Nut

.....x4

.....x4

36850
7mm Ball

3x16mm

3x25mm

3mm

ASSEMBLY OF THE REAR STABILIZER

94033
3x3mm
Set Screw

.....x4

94002
3x8mm
Hex Screw

.....x4

3x8mm

3x8mm

3x3mm

3x3mm

3x3mm

40533

40533

40686

3mm

Approx 7mm.

36850

36850

40661

40540

40540

NO.5

BAG

NO.5

BAG

NO.5

BAG

0

10

20

30

40

50

60
