ASSEMBLY OF THE FUEL TANK ONTO CHASSIS

ASSEMBLY OF THE CLUTCH

ASSEMBLY OF THE CLUTCH AND ENGINE MOUNT

Step 1

Step 2

Step 1

Step 2

10013

10101

3x12mm

*Place the clutch shoes with the clutch
springs over the 3 pins of the flywheel.
*Using a FLAT screw driver or needle
nose pliers and bend the small end of
the clutch spring behind the pilot shaft
10098 than press down.

10098

40573

38313

40574

10399

34110

3x8mm

3x5mm

5x9x0.3mm

.....x1

.....x4

3x5mm
Cap Screw

3x12mm
Cap Screw

2.6x5mm
Washer

37410

NO.9

BAG

*Fit the flywheel using a pair of the
plIer and cross wrench.

NO.8

BAG

NO.8

BAG

.....x2

34110
5x10x4mm
Ball Bearing

.....x1

5x9x0.3mm
Washer

3x8mm
Washer

.....x4

3x5mm
Spring Washer

3x5mm
Spring
Washer

94038

10098
