OFNA Racing Jammin X2 Truggy User Manual
Page 26
54
55
56
ASSEMBLY OF THE FUEL TUBE AND PRESSURE TUBE
ASSEMBLY OF THE WING
ASSEMBLY OF THE TIRES AND WHEELS
19
Connect to carbulater.
Connect to fuel nipple.
Connect to fuel tank nipple.
Connect to pressure nipple.
Step 1
Step 3
Step 2
IN
S
T
A
N
T
G
L
U
E
Apply instant glue into the groove of the wheel.
10177
3x12mm
40542
16015
81106
80022
86106
94004
3x12mm
Hex Screw
.....x2
Drill two 7mm holes for mounting.
Body Reamer (Not included)
Connect to fuel filter.
40542
3x12mm
