OFNA Racing Jammin X2 Truggy User Manual

Page 25

background image

51

52

53

ASSEMBLY OF THE FRONT SHOCK ABSORBER

ASSEMBLY OF THE REAR SHOCK ABSORBER

ASSEMBLY OF THE FRONT BUMPER

18

Assembly for both right and left side.

Assembly for both right and left side.

3mm

3x20mm

4x16mm

Step 1

Step 2

.....x3

94004
3x12mm
Hex Screw

94003
3x10mm
Hex Screw

.....x6

3x10mm

3x12mm

40669

94027
4x16mm
Flat Head Hex Screw

.....x2

3x10mm

40669

40669

40669

3x10mm

40643

3mm

94007
3x20mm
Hex Screw

.....x1

.....x2

94040
3x8mm Washer

94041
3mm
Nylon Nut

.....x2

40643

3x8mm

3x12mm

3x8mm

40559
Left Thread Hex Screw(Siliver)

40559
Left Thread Hex Screw(Siliver)

.....x1

94007
3x20mm
Hex Screw

.....x1

.....x2

94040
3x8mm Washer

94041
3mm
Nylon Nut

.....x2

.....x1

Rotate
Direction

3x20mm

40559

40559

Rotate
Direction

Use left thread
screw on the front
right arm.

Use left thread
screw on the rear
left arm.

Front bumper assembly.

Anti-Clockwise

Anti-Clockwise
