No.2, No.5, No.5 no.4 – OFNA Racing Jammin X2 Truggy User Manual

Page 15

ASSEMBLY OF THE WING STAY

ASSEMBLY OF THE REAR WHEEL HUBS

ASSEMBLY OF THE REAR SUSPENSION ARMS

Step 1

Step 2

Assemble both right and left sides

4x16mm

94009
4x10mm
Hex Screw

.....x1

94034
4x4mm
Set Screw

.....x2

94041
3mm
Nylon Nut

.....x2

3mm

4x10mm

4x20mm

94011
4x16mm
Hex Screw

.....x4

94012
4x20mm
Hex Screw

.....x1

94041
3mm
Nylon Nut

.....x2

w n

Step 1

Step 2

36053

40657

36055

4x4mm

40526

40540

4x10mm

40540

3mm

36870
4x10mm

Set Screw

.....x2

36055
2.5x16mm Pin

.....x2

36053
8x16mm Ball Bearing

.....x4

Assemble both right and left sides

94042
4mm
Nylon Nut

.....x2

40604

40603
(Long)

41034

40540

NO.2

BAG

NO.5

BAG

NO.5

NO.4

BAG

NO.5

*A 4x10mm set screw is used
to adjust the ride-height.

4x10mm
Set Screw

4mm
Nylon Nut

Approx 2mm

*Insert the drive shaft
into the cap joint before
assembly.

Wheelbase
adjust washer

30776

Insert two 30776 washer
into arm shaft before
assembly.

.....x1

30776
4x10mm Washer

40668
