31

32

33

ASSEMBLY OF THE FRONT GEAR CASE ONTO CHASSIS

ASSEMBLY OF THE CENTER DIFF. ONTO CHASSIS

ASSEMBLY OF THE REAR GEAR CASE ONTO CHASSIS

94019
3x10mm
Flat Head Hex Screw

.....x1

94019
3x10mm
Flat Head Hex Screw

.....x2

3x10mm

4x20mm

4x20mm

41035

11

94026
4x12mm
Flat Head Hex Screw

.....x4

94028
4x20mm
Flat Head Hex Screw

.....x4

94039
4x10mm
Flat Head Hex Screw

.....x2

94027
4x16mm
Flat Head Hex Screw

.....x2

4x12mm

4x12mm

3x10mm

4x16mm

4x10mm

4x10mm

Screw

Ceme

nt

Screw

Cemen

t

Screw

Cemen

t

NO.2

BAG

NO.4

NO.5

BAG

NO.6

BAG
