No.7, No.5, No.9 – OFNA Racing Jammin X2 Truggy User Manual

Page 20

ASSEMBLY OF THE RADIO TRAY ONTO CHASSIS

ASSEMBLY OF THE FUEL TANK

ASSEMBLY OF THE FUEL TANK POST
ONTO CHASSIS

41035

Step 1

Step 2

Step 3

3x10mm

40620BK

94019
3x10mm
Flat Head Hex Screw

.....x2

3x10mm

41035

41051

3x10mm

41035

41037

94019
3x10mm
Flat Head Hex Screw

.....x7

94004
3x12mm
Hex Screw

.....x1

3x12mm

3mm

NO.7

BAG

NO.5

BAG

NO.9

BAG

94003
3x10mm
Hex Screw

.....x1

94041
3mm
Nylon Nut

.....x1

*Cut on
these line.

* Choose the right
length for your car.
