40011

1

2

3

ASSEMBLY OF THE FRONT AND REAR DIFF.

ASSEMBLY OF THE FRONT AND REAR DIFF.

ASSEMBLY OF THE CENTER DIFF.

Step 1

Step 2

36053
8x16mm Ball Bearing

94034
4x4mm
Set Screw

40010
2.5x13.8mm Pin

.....x4

.....x4

.....x4

.....x2

40009
P6 O-Ring

Builds two differentials for front and rear.

.....x16

30776
4x10mm Washer

30774
4mm
Alum. Cross Pin

.....x4

3x12mm

94020
3x12mm
Flat Head Hex Screw

.....x8

1

Tight the diff screws in this order.

1

4

3

2

Step 1

Step 2

Oil

36053

40513

40009

41031

30774

40513

30776

Tighten

Step 1

Step 2

40009

Oil

Oil

36053

4x4mm

40513

40538

40010

36053

40513

40009

40518

40605

36053
8x16mm Ball Bearing

94034
4x4mm
Set Screw

40010
2.5x13.8mm Pin

.....x2

.....x2

.....x2

.....x1

40009
P6 O-Ring

*Put the Diff. Oil #7000 for front
and the #3000 for rear.
*Fill the Diff. case to approx. 80%
with the Diff. Oil.

Di

f. O

f

il

40605

40010

40010

40596

40596

40009

Oil

36053

4x4mm

40513

40538

40010

NO.1

BAG

NO.1

BAG

NO.1

BAG
