No.10 – OFNA Racing Jammin X2 Truggy User Manual

Page 24

ASSEMBLY OF THE FRONT SHOCKS

ASSEMBLY OF THE REAR SHOCKS

Step 1

Step 2

Step 3

Step 4

Step 5

Step 7

Step 6

*Assemble 2 sets for front

*Assemble 2 sets for rear

40643
(Short)

40054
(Short)

2.6x5mm

41005

41013

40058

41008

41017

1.Pull down piston and pour oil into shock
cylinder.
2.To remove air bubbles by slowly moving
piston up and down.
3.Pull down piston, attach pressure top and
clean shock oil overflow with tissue paper.

41012
2mm Washer

.....x2

30403
6mm Ball

41012
1mm Washer

.....x2

41008

41012

41019

41012

41003

2.6x5mm

41011

*Cut 7mm for front.

41012
3.5mm O-Ring

.....x4

Step 1

Step 2

Step 3

Step 4

Fit the o-ring into
groove before
assembly.

Fill the shocks with
oil #50.

Fill the shocks with
oil #60.

Step 5

Step 6

Step 7

41007

41006

40643
(Long)

40055
(Long)

2.6x5mm

41005

41013

40058

30403

41017

41012
2mm Washer

.....x2

30403
6mm Ball

41012
1mm Washer

.....x2

41008

41012

41019

41012

#387B

41011

41012
3.5mm O-Ring

.....x4

41019
10mmx1mm O-Ring

.....x2

41019
10mmx1mm O-Ring

.....x2

41006

2.6x5mm

41008

40060

NO.10

BAG

Do Not
Over Tighten

Oil

Carefully screw the shock shaft into
the bottom of the plastic ball end
untill the distance between the ball
end and the shock body is 37.5mm
for the rear .
N.B. Do not over tighten as the
plastic will strip.

Carefully screw the shock shaft into
the bottom of the plastic ball end
untill the distance between the ball
end and the shock body is 28

for the front .
N.B. Do not over tighten as the
plastic will strip.

CORRECT SHOCK ASSEMBLY

Be careful not to
damage shock shaft.

*Use Short ball end
for front.

*Use long ball end
for rear.
