No.1, No.2 – OFNA Racing Jammin X2 Truggy User Manual

Page 8

background image

4

5

6

ASSEMBLY OF THE CENTER DIFF.

ASSEMBLY OF THE FRONT GEAR CASE

ASSEMBLY OF THE FRONT ARMS HOLDER

Step 2

4x35mm

4x16mm

Adjust the backlash with
the shims.

40024
13x16x0.2mm Shim

36053
8x16mm Ball Bearing .....x2

94015
4x35mm Hex Screw

.....x2

94011
4x16mm Hex Screw

.....x2

2

*

*

Use 10000 weight diff. oil in the

center.

Fill the Diff. Case to approx. 80%

with the Diff.Oil.

40533

40688

40011

Step 1

Step 2

.....x8

30776
4x10mm Washer

30774
4mm
Alum. Cross Pin

.....x4

3x12mm

94020
3x12mm
Flat Head Hex Screw

.....x4

Tight the diff screws in this order.

1

4

3

2

40513

30776

Tighten

Di

f.

f

Oil

Step 1

Apply
Grease

40024

40533

40024

36053

41032

36053

.....x4

5x4mm

41044

40589

40534

Caster angle can
be changed with
A or B

4x16mm

4x12mm

Steering
Characteristics

Steering response
becomes milder.

Steering response
becomes quicker.

Caster
(High/22 Degree)

Caster
(Low/20 Degree)

A

B

Sc

ew

r

C

men

e

t

NB. use only as matched set "A"
with"A"and "B" with "B".

A

A

94036
5x4mm
Set Screw

.....x1

94026
4x12mm
Flat Head Hex Screw

.....x2

94027
4x16mm
Flat Head Hex Screw

.....x2

30774

NO.1

BAG

NO.2

BAG

NO.2

BAG
