BP Filter is an automatically sweepable
Band Pass Filter, with the following
response:
P1 • Frequency 31.5 Hz 16 kHz
Sweep
min 0.7
max 6.0
• P2 Resonance
• P2 P1 •
single
tap BPM
sync
point,
multiple
taps to
set BPM.
Depth min
HP Filter is an automatically sweepable
High Pass Filter, with the following
response:
(In case you are wondering, a high pass
is the same as a low cut.) Each Filter’s
settings are independent from the other
Filters.
P1 Frequency / Tap BPM
If the track has a BPM tag, the Filter
sweep automatically matches it and a
lock icon appears in the Filter section.
To manually set the sweep BPM, tap
P1
to the beat. The default BPM is 120, and
tapping
P1 can set it from 24 to 480 with a
resolution of 0.1 BPM. A single Tap of P1
resyncs the sweep to the BPM.
The primary function of
P1 (indicator off)
is Cutoff Frequency, which starts at 722
Hz and is adjustable from 31.5 Hz to 16
kHz (9 octaves). The full sweep of the filter
is reached in 1
1 /
3
rotations of P1.
J1 Multiplier
The BPM Multiplier is selected with
J1, which toggles between transform
operation and BPM multiplier. If the green
mode indicator is on,
J1 may adjust the
multiplier to 16, 8, 4, 2, 1, ¾, ½, or ¼.
P1 •
Frequency 31.5 Hz 16 kHz
Sweep
• P2
max 3.0
min 0.7
P1 •
single
tap BPM
sync
point,
multiple
taps to
set BPM.
Depth min
• P2 Resonance
Sweep Filter Control
Assignments
Three Filters have the same parameters,
but are different filter types:
LP Filter is an automatically sweepable
Low Pass Filter, with the following
response:
GROUP DECK
P1 P2
J1
B1 B2
1 2
B3 B4 B5 B6
J2
PROCESSOR 1
FREQUENCY RESONANCE
DEPTH TAP BPM
PROCESSOR 2 MULTIPLIER
PGM 1 PGM 2 AUX B MAIN ON ON
INSERT POINT CUE EFFECT
ALL WET
MORE
DRY
ALL DRY
MORE
WET
1
3/4
1/4 8
2
1/2
16
4
P1 • Frequency 31.5 Hz 16 kHz
Sweep
max 3.0
min 0.7
• P2 P1 •
single
tap BPM
sync
point,
multiple
taps to
set BPM.
Depth min
• P2 Resonance
