Rane SR 2 User Manual
Page 3
Manual-3
Front Panel Description
1
Colored insert
(4 colors
included).
2
Clear lens
helps support dif-
ferent color templates which
mount behind the lens.
3
LED indicators
. Indicate the
current “level” of the linked
parameter(s).
4
Encoder Knob with mo-
mentary push switch
is the
user input to the SR 2.
1
2
4
3
