Rane SR 2 - Manual (Page 16)

Manual-16
Cable Type 2
4 twisted pair unshielded CAT 5, Belden #1583(A, B, E, ENH, R)
4 twisted pair shielded CAT 5, Belden #1624 (P, R)
4 twisted pair unsheilded CAT 5, Belden #1700 (A, R)
Note: This table is only for systems using SR 2 remotes (all remotes on 485 bus are
the same). For mix and match calculation of SR 2, SR 3 and SR 4 Remotes, use the
SRCABLELENGTH.XLS Microsoft Excel™ spreadsheet on the Drag Net CD-ROM or
at www.rane.com/sr2.html.
Requires
external
supply
Max Distance
for Cable (feet)
Max Distance for
Cable (meters)
Number of
SR 2 Remotes
Vs = 15V
RPM 44
RPM 22
1000 305 1
1000 305 2
1000 305 3
1000 305 4
1000 305 5
1000 305 6
1000 305 7
1000 305 8
Vs = 12V
RPM 88
1000 305 1
1000 305 2
1000 305 3
1000 305 4
1000 305 5
946 288 6
822 251 7
727 222 8
Vs = 8V 769 235 1
477 145 2
345 105 3
271 83 4
223 68 5
189 58 6
164 50 7
145 44 8
